S19 Bitmain Ant Bitcoin Miner XP PRO Hydro Cooling 198T

Product Details:
Place of Origin: China
Brand Name: Bitmain Ant
Model Number: S19 Pro+ Hyd
Payment & Shipping Terms:
Minimum Order Quantity: 10stages
Price: Negotiable
Packaging Details: Carton
Delivery Time: pre order
Payment Terms: USDT
Supply Ability: 100 PIECES/DAY
  • Detail Information
  • Product Description

Detail Information

Product Name: S19 XP PRO Hydro-cooling Model: S19 Pro+ Hyd
Algorithm | Cryptocurrency: SHA256 | BTC/BCH/BSV Hashrate, TH/s: 198 ±3%
Power On Wall @35°C, Watt(1-1): 5445 ±5% Power Efficiency On Wall @35°C, J/TH(1-1): 27.5 ±5%
Power Supply AC Input Voltage, Volt(2-1): 342~418 Power Supply AC Input Frequency Range, Hz: 47~63
Power Supply AC Input Current, Amp(2-2): 30 Networking Connection Mode: RJ45 Ethernet 10/100M
Miner Size (Length*Width*Height, W/o Package),mm: 410*196*209 Net Weight, Kg: 15.2
Operation Temperature,°C(2-3): 0~40 Inlet Water Temperature,°C: 20-40
Water Flow L/min: 8±10% Water Pressure Bar: ≤3.5
Storage Temperature, °C: -20~70 Operation Humidity(non-condensing) , RH: 10~90%
High Light:

Bitmain Ant Bitcoin Miner


Hydro cooling Miner 198T


XP PRO Antminer BTC Miner

Product Description

Bitmain Ant Bitcoin Miner S19 XP PRO Hydro-cooling Miner 198T:
Bitmain, one of the largest mining machine manufacturers in the world, has released a new ant mining machine S19PRO Hyd, with a computing
power exceeding the current strongest mining machine, with a maximum hash value of 198T per second, which is currently the strongest in the
world. Great bitcoin miner. S19 XP PRO 198T can have such a high computing power, its secret weapon is "water".
The S19 XP PRO 198T Hyd mining machine abandoned the traditional air cooling system and changed it to a water cooling system for cooling
operation and mining. This is a very novel design, making the miner suitable for large-scale mining, and miners no longer need to find someone to
help transform the water cooling system.
Hydro-cooling Miner&Air-cooled mining machine:
Since the first ASIC mining machine appeared in 2013, the chips are getting smaller and smaller, and the hash value is getting higher and higher.
From 10G per miner to the current 140T hash value of each miner, in terms of optimal energy consumption ratio, ASIC miners have basically
approached or reached the physical limit of ASIC air cooling. For air cooling, it mainly uses the hot and cold air circulation to take away the heat
generated by the mining machine, which is easy to cause local hot spots. Yes, the machine is prone to frequent disconnection, loss of computing
power, high temperature protection and other problems, reducing the service life of the mining machine. . Coupled with high energy consumption,
high electricity cost, and market environment impact, it is a very big challenge for miners (unless they get a very ideal electricity price).
The water-cooling method is different. Since the water-cooled plate is attached to the chip at almost zero distance, the specific heat capacity of
water is larger than that of oil, and the density is 10,000 times that of air. Therefore, the rapid flow of water can realize most of the heat energy.
Walk. In addition, the fan work is abandoned, except for the sound of water flow, no other noise will be produced.
Liquid-cooled mining machine:
Of course, the Ant water-cooled mining machine is currently in the pre-order stage, and the price of the high-power water-cooled mining machine is relatively expensive. Miners have limited funds and can still choose traditional air-cooled mining machines, and then transform air-cooled into a liquid-cooled system. It can achieve noise-free operation of the mining machine, and at the same time, the temperature of the mining machine can be controlled by adjusting the water flow to avoid disconnection and loss of computing power caused by high temperature protection. If the mining machine needs to be resold for a second time, it only needs to be cleaned by ultrasonic waves and the fan can be restored. The liquid-cooled mining machine controls the temperature of the mining machine by controlling the flow rate and the modified silicone paper, which can achieve 5%~20% overclocking.
The costs required for the transformation of the liquid-cooled mining machine are mainly: special silicone paper, coolant (transformer oil/insulating oil), boxes for placing the liquid-cooled mining machine, labor costs, etc.
If you are interested in this, you can contact our business Miss. Wei, WhatsApp: +8615123100414.

Detailed Features:

The algorithm of S19PRO+ Hyd still continues the SHA-256 algorithm of Bitmain Antminer. SHA-256 is currently the only hash algorithm with no known vulnerabilities. SHA-256 is a one-way function with fast calculation speed and is resistant to pre-images. It is widely regarded as one of the most secure and advanced algorithms by cryptographers around the world, and its security need not be worried.
The SHA-256 algorithm can mine Bitcoin, Bitcoin Cash, BSV and other virtual currencies.
Computing power:
The computing power of S19PRO+ Hyd can be as high as 198T. At present, there is no Bitcoin mining machine with a higher hash value than S19PRO+ Hyd. Higher hash value means more computing power, which can quickly verify transactions and increase revenue.
Power consumption:
The energy consumption of S19PRO+ Hyd is 5,445 W and the energy efficiency is 27.5 J/TH. With such a huge energy consumption, Bitmain recommends users to use their specially designed mining machine storage cabinet Antspace HK3. This container-like mining rack provides 1MW of power and can Supply 210 sets of S19 PRO Hyd miners for use.

Product NameS19 XP PRO Hydro-cooling
ModelS19 Pro+ Hyd
Algorithm | CryptocurrencySHA256 | BTC/BCH/BSV
Hashrate, TH/s198 ±3%
Power on wall @35°C, Watt(1-1)5445 ±5%
Power efficiency on wall @35°C, J/TH(1-1)27.5 ±5%
Power supply AC Input voltage, Volt(2-1)342~418
Power supply AC Input Frequency Range, Hz47~63
Power supply AC Input current, Amp(2-2)30
Networking connection modeRJ45 Ethernet 10/100M
Miner Size (Length*Width*Height, w/o package),mm410*196*209
Net weight, kg15.2
Operation temperature,°C(2-3)0~40
Inlet water temperature,°C20-40
Water flow L/min8±10%
Water pressure bar≤3.5
Storage temperature, °C-20~70
Operation humidity(non-condensing) , RH10~90%
